The Short Answer

Site plans and property maps need to be printed on a large-format plotter, not a standard office printer, and the scale has to be locked in before the print runs.

At QuikPrint in Oakville, site plans and property maps print the same way blueprints and CAD drawings do — through large-format plotting, in black & white or colour, at true architectural scale (1:50, 1:100, 1:200, and others).

Bring the file in as a PDF, DWG, or DXF, tell us the scale you need, and we’ll confirm sizing before anything gets printed.

Why You Can’t Just Print a Site Plan at Home

A site plan is a scale drawing. Every inch on the page represents a fixed distance on the ground — say, 1 inch equals 20 feet. That relationship only holds if the page prints at 100% size, with no “fit to page” resizing.

Home and office printers max out at legal or tabloid size, and most default settings shrink the file to fit. The moment that happens, your scale bar is no longer accurate. A contractor measuring off that print will get the wrong setback, the wrong lot line, the wrong distance to the property edge.

This is the same issue we cover in our guide on blueprint printing costs in Oakville — large-format printing exists specifically because construction, survey, and planning documents are useless if they’re printed off-scale.

What Counts as a “Site Plan or Property Map”

This isn’t just one document type. We regularly print:

– Survey plans — legal property boundaries, prepared by an Ontario land surveyor

– Site plans — building placement, setbacks, driveways, and grading for permit submissions

– Severance and consent plans — for property line changes or lot splits

– Landscaping and grading plans — drainage, elevation, planting layout

– Subdivision and plan of survey documents — for real estate or legal purposes

– Municipal zoning maps — printed from a town or city GIS portal

If it has a scale bar, a north arrow, and property lines, it belongs on a plotter — not a desktop printer.

Getting the Scale Right

Before we print anything, we confirm two things: the file’s original scale, and the paper size that scale needs.

If the file is a PDF from your surveyor or architect, the scale is usually already locked into the document. We print it at 100% — no resizing — so the scale bar stays accurate.

If the file is a DWG or DXF from AutoCAD or similar software, we confirm the drawing scale and plot it to match. This is common for site plans built by engineers or planners.

If you pulled a zoning map or property map from a municipal website, these are often exported as a screenshot or low-resolution PDF. We’ll check the resolution first — a blurry source file will print blurry no matter what paper size you choose. If the source is too low-res, we’ll let you know before you pay for a print that won’t hold up.

Don’t have a digital copy of your survey at all? Ontario’s Land Registry portal, [OnLand](https://www.onland.ca), lets property owners pull an official parcel map PDF for a small fee — that’s often the fastest way to get a clean, print-ready file before you come in.

Common site plan and survey sizes we print:

| Sheet Size | Typical Use |

| 11″ × 17″ | Small lot survey, single-page site plan |

| 18″ × 24″ | Standard residential site plan |

| 24″ × 36″ | Full site plan with grading and landscaping detail |

| 36″ × 48″ | Subdivision plans, multi-lot surveys |

Who Actually Orders These

Most of the site plan and property map printing we do at QuikPrint comes from:

– Homeowners submitting a permit application to the Town of Oakville — deck, addition, fence, or pool

– Realtors who need a clean survey copy for a listing package or closing

– Landscapers and contractors working from a grading or planting plan on-site

– Property buyers who want a clear copy of the survey before closing, especially on older homes where boundaries aren’t obvious

– Lawyers and title companies who need certified-looking copies for a file

If you’re pulling a permit through the Town of Oakville, the site plan almost always needs to be printed at a specific scale and sometimes in multiple copies — check your permit checklist before you order so you don’t have to reprint.

Black & White or Colour?

Most site plans and property maps print fine in black & white — the lines, boundaries, and dimensions are what matter, and B&W plotting is the more affordable option. This is the same pricing structure covered in our blueprint printing cost breakdown.

Colour is worth it when the map uses colour to communicate something — zoning overlays, elevation shading, drainage flow arrows, or a landscaping plan with plant/material legends. If colour is doing real work in the file, don’t print it in black & white. You’ll lose the information the colour was there to show.

What File Formats We Accept

Bring your site plan or property map in any of these:

– PDF (preferred — especially if the scale is already locked in)

– DWG

– DXF

– TIFF

– High-resolution JPEG (screenshots from municipal GIS portals — check resolution first)

Email files ahead to hi@quikprint.ca or bring them on a USB drive. If you’re not sure the file will hold up at large-format size, ask before you order — we’ll check resolution and scale before we print.

Don’t Have a Digital File? We Can Scan It

If your only copy of a site plan or survey is an old paper print — common with older Oakville properties where the original survey is decades old — we can scan it and hand back a clean digital file at high resolution, up to 36″ × 48″.

That gives you a PDF you can email to a lawyer, contractor, or the municipality instead of guarding one fragile paper original. See our full breakdown of large format scanning services in Oakville for sizes and turnaround.

Same-Day Turnaround

Most site plans and property maps print same day at our Oakville location. If you’re heading into a permit office or a closing and need it that afternoon, call ahead at (289) 386-5005 so we can confirm sizing before you arrive — that way there’s no back-and-forth once you’re standing at the counter.

Get Your Site Plan or Property Map Printed in Oakville

QuikPrint is located at 2526 Speers Rd, Unit 14, Oakville — just off the QEW.

Email your file, walk in with it on a USB drive, or ask us to scan an existing paper copy. We’ll confirm scale and paper size before anything prints, so what you get back matches what you need — no cut-off edges, no distorted scale.

We’re open until 7 PM, so a plan due tomorrow morning is still doable today.
